Maks.afbr. NSX100H+TM63D 3P3D

Varenr.: [24162434] | Producent: Schneider Schreibgeräte | Model-nr.: 10450726 | EAN: 3606481998484
Útselt í løtuni, óviss veitingartíð
Útselt í løtuni, óviss veitingartíð. Meira kunning
Leveringsmuligheder  - Vælges ved checkout
Heintast
ÓKEYPIS
Útbering.
60,00
DKK 8.265,00
Uttan MVG 6.612,00
Prísur við heinting í Tórshavn ella Klaksvík 8.265,00
Gev mær boð tá vøran er tøk aftur
Læs yderligere specifikationer og beskrivelse

This ComPacT NSX100H is a complete 3P 3d fixed circuit breaker designed to optimize space and breaking capacity. It is an optimal choice for all standard and specific applications. The breaking capacity (Icu) is 70kA rms at 415VAC 50/60Hz. The operational voltage is 690VAC 50/60Hz. This product embeds a 63A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 3 poles version (105mm x 161mm x 86mm) comes with a variety of optional functions and accessories. It is compliant with international standards (IEC 60947), CCC, EAC and marine specifications. ComPacT NSX100H is part of Schneider Electric EcoStruxure Power architecture.
